MP7505 Series User Manual
Restore to the user setting
(1) To save the current system setting as a user-defined setting, refer to Save/recall
Instrument Settings on page 58.
(2) Press the front panel Preset function key to enter the preset menu.
(3) Press the ResetSet softkey to select User.
(4) Press the User softkey to select the desired user setup file (Setup0 to Setup15).
Note: Before selecting any of Setup0 to Setup15, make sure that valid setting file
is stored in the corresponding storage location.
(5) Press the Reset softkey, and press the OK softkey to restore the generator to the
selected user-defined setting.
Power-on setting
Set the settings to be used when the instrument is powered on the next time to a
specified setting.
(1) Press the front panel Preset function key to enter the preset menu.
(2) Press the PowerOn softkey to select power-on settings as Last, User or Factory.
Last
When powered, restore the generator to the setting at last shutdown.
User
When powered, restore the generator to a user-defined setting.
To save the current system setting as a user-defined setting, refer to Save/recall
Instrument Settings on page 58.
Press the User softkey to select the desired user setup file (Setup0 to Setup15).
Note: Before selecting any of Setup0 to Setup15, make sure that valid setting file
is stored in the corresponding storage location.
Factory
When powered, restore the generator to factory default settings. The factory
default settings are in Table 5-1.
Use Build-in Help (Help)
(1) To get help about any front panel button or menu softkey, first press the front
panel Help function button, then press the button you need help with.
(2) Press the Help function button again to exit the help interface.
