MP7505 Series User Manual
USB Device Type
The user can set the communication protocol type of the USB Device interface at the
rear panel.
(1) Press the front panel Utility function key, press the I/O Setup softkey.
(2) Press the USBDEV softkey to toggle between PC and USBTMC.
PC: This is the internal communication protocol. Select this option when
connecting to the Waveform Editor software via the USB Device interface.
For details, refer to Using USB Port on page 64.
USBTMC: Select this option when you need to use the USBTMC
communication protocol standard.
Network Setting
The user can examine network status and configure network settings.
(1) Press the front panel Utility function key, press the I/O Setup softkey.
(2) Press the Network setting softkey to go to the submenu: IP Address, Gateway,
Subnet mask, Port. The physical Mac address displayed on the interface cannot
be modified.
Press the IP Address softkey to select IP Address. Use the numeric keypad
and direction keys to enter the desired IP address. The IP address format is
nnn.nnn.nnn.nnn, where nnn ranges from 0 to 255. It is recommended that
your aquire an available IP address from your network administrator.
Press the Gateway softkey to select Gateway. Use the numeric keypad and
direction keys to enter the desired gateway. The gateway format is
nnn.nnn.nnn.nnn, where nnn ranges from 0 to 255. It is recommended that
your aquire an available gateway from your network administrator.
Press the Subnet mask softkey to select Subnet mask. Use the numeric
keypad and direction keys to enter the desired subnet mask. The subnet
mask format is nnn.nnn.nnn.nnn, where nnn ranges from 0 to 255. It is
recommended that your aquire an available subnet mask from your
network administrator.
Press the Port softkey to select the Port. Use the numeric keypad and
direction keys to enter the desired port, which ranges from 0001 to 4000.
(3) After setting the network parameters of the generator, you need to wait for 2
seconds or more to restart the instrument, the current settings of the LAN
parameters will take effect. For details, refer to Using LAN Port on page 65.
