MP7505 Series User Manual
External clock input
Impedance 1MΩ, AC coupling
Input level range 1Vpp to 3.3Vpp
Lock time <1s
Lock range 10 MHz ± 50Hz
Internal clock output
Frequency 10 MHz ± 50Hz
Impedance 50 Ω, DC coupling
Amplitude 1.2Vpp (50Ω)
Sync Output
Level 3.3V LVTTL
Impedance 50 Ω, DC coupling
Maximum frequency 1MHz
General Specifications
Display
Display type 7-inch color LCD display
Display resolution 800 Horizontal ×480 Vertical pixels
Display color 65536 colors, 16 bits, TFT
Touch screen (Optional) capacitive, multi-touch
Power
Voltage 100 - 240 V (± 10%), 50 / 60 Hz
Power consumption Less than 50VA
Fuse 250V, F2AL
Environment
Temperature
Working temperature: 0 °C to 40 °C
Storage temperature: -20 °C to 60 °C
Relative humidity
Less than 35°C: ≤ 90% relative humidity
35°C to 40°C: ≤ 60% relative humidity
Height
Operating 3,000 meters
Non-operation 12,000 meters
Cooling method Smart fan cooling
Mechanical Specification
Dimension 340 mm (Length) × 177 mm (Height) × 90mm (Width)
Weight Approx. 2.3 kg
Others
IP protection IP2X
Adjustment interval The recommended calibration interval is one year
