MP7505 Series User Manual
72
Internal modulation
waveform
Sine, square, ramp, white noise, and arbitrary waveforms (except DC)
Internal phase
modulation frequency
2 mHz to 1 MHz
Offset 0 to min (min is the smaller value of pulse wave duty cycle and
100%-pulse wave duty cycle)
ASK
Carrier Sine wave, square wave, ramp wave, arbitrary wave
Modulated signal source Internal or external
Internal modulation
waveform
50% square wave
ASK frequency 2 mHz to 1MHz
PSK
Carrier Sine wave, square wave, ramp wave, arbitrary wave
Modulated signal source Internal or external
Internal modulation
waveform
50% square wave
PSK frequency 2 mHz to 1MHz
FSK
Carrier Sine wave, square wave, ramp wave, arbitrary wave
Modulated signal source Internal or external
Internal modulation
waveform
50% square wave
FSK frequency 2 mHz to 1MHz
3FSK
Carrier Sine wave, square wave, ramp wave, arbitrary wave
Modulated signal source Internal
Internal modulation
waveform
50% square wave
FSK frequency 2 mHz to 1MHz
4FSK
Carrier Sine wave, square wave, ramp wave, arbitrary wave
Modulated signal source Internal
Internal modulation
waveform
50% square wave
FSK frequency 2 mHz to 1MHz
BPSK
Carrier Sine wave, square wave, ramp wave, arbitrary wave
Modulated signal source
Internal
Internal modulation
waveform
50% square wave
BPSK frequency 2 mHz to 1MHz
