Non-harmonic distortion
Typical (0dBm)
≤10MHz: <-70dBc
>10MHz: <-70dBc + 6dB/ sound interval
Phase noise
Typical (0dBm, 10kHz offset)
10MHz: ≤-110dBc/Hz
Square
Rise/fall time < 8ns
Jitter (rms), typical (1Vpp, 50Ω)
≤5MHz: 2ppm + 300ps
>5MHz: 300ps
Overshoot Typical (100 kHz, 1 Vpp) < 3%
Duty cycle 50.00% (fixed)
Ramp
Linearity
< 0.1% of peak output
(typical 1 kHz, 1 Vpp, symmetry 50%)
Symmetry 0.0% to 100.0%
Pulse
Period
MP750513
MP750512
MP750511
40 ns to 1000 ks
MP750510 66.667 ns to 1000 ks
Pulse Width
MP750513
MP750512
MP750511
≥ 12ns
MP750510 ≥ 18ns
Duty cycle 0.3% to 99.6% (limited by the frequency setting)
Rise and fall time ≥ 8ns (limited by the pulse width setting)
Overshoot < 3%
Jitter (rms), typical (1Vpp, 50Ω)
≤5MHz: 2ppm + 300ps
>5MHz: 300ps
Noise
Types Gaussian white noise
Bandwidth (-3dB)
MP750513 100 MHz BW
MP750512 80 MHz BW
MP750511 60 MHz BW
MP750510
35 MHz BW
Arbiratry wave
Waveform length 2 to 10M points
Sampling rate 500M Sa/s
Amplitude accuracy 14 bits
Minimum rise and fall time < 8 ns
Jitter (rms), typical (1Vpp, 50Ω)
≤5MHz: 2ppm + 300ps
>5MHz: 300ps
Harmonic wave
Harmonic number ≤16
Harmonic type Odd, even, sequential, custom
