5.5 Inspection Menu
This menu displays the following items on Operation panel.
Table 5-1 Diagnosis Items for Inspection Menu
Diagnosis item Contents Reference
Ram capacity Displays the size of memories installed on the MAIN
board Assy .
"5.5.1 Ram
Capacity Menu" p.5-
9
Version Displays the following items on Operation panel:
• Firmware version
• Backup parameter version
• Setting of dip switches of MAIN board Assy
• Revision of MAIN board Assy
• Company code
•Serial No.
"5.5.2 Version
Menu" p.5-10
Panel Used to check the operations of Operation panel keys,
LCD, and LED.
"5.5.3 Panel
Menu" p.5-11
Sensor Displays the status of the following sensors:
• CR origin sensor
• Waste fluid tank sensor
•Wiper sensor
• Cover sensor
• Maintenance cover L sensor
• Maintenance cover R sensor
•Lever sensor
• Paper edge sensor
• Paper rear sensor
• Head Gap
• Head thirmistor sensor
• Head Trans.1/2
• INK NOT （4 colors）
• INK END （4 colors）
• INK ID （4 colors）
• Cutter Solenoid
• Choke Valve
"5.5.4 Sensor
Menu" p.5-12
Encoder Displays the detected values from the following
encoders:
• CR encoder
• PF encoder
"5.5.7 Encoder
Menu" p.5-16
Fan Used to check if the following fans operate normally by
turning them ON and OFF:
• Suction Fan
• Cooling fan (24V) Assy (for MAIN board Assy)
"5.5.8 Fan
Menu" p.5-17
Record Used to check the following records. Used to initialize
the serious error history.
• Maintenance history
• Serious error history
• Confirming Printing information
• Confirming Operating Time
• Confirming S/C Log
"5.5.9 Record
Menu" p.5-18
Head signal Used to check the head-driving waveform. "5.5.10 Head
Signal Menu" p.5-24
Spectro Vue Check the connection of Spectro Vue "5.5.11 Spectro
Vue Menu" p.5-25
Time Check Confirming RTC activation "5.5.12 Time
Check Menu" p.5-26
Table 5-1 Diagnosis Items for Inspection Menu (Continued)
Diagnosis item Contents Reference
