7.4.1 Required Tools P.7-6
7.4 Jigs and Tools VJ1324E-M-02
7.4 Jigs and Tools
This section provides lists of jigs and tools required for service operations.
7.4.1 Required Tools
(1) Tools for Part Replacement
(2) Tools for Adjustment
Table 7-3 Tools for Part Replacement
No. Name Part number Remarks
1 Phillips driver No.2 Generic product More than 250 mm shaft length is
recommended.
2 Phillips driver No.2 Generic product Less than 50 mm shaft length is
recommended.
3 Phillips driver No.1 Generic product -
4 Flat-head driver Generic product For replacing E rings
5 Box driver Generic product For replacing CR board assemblies
6 Ratchet Generic product -
7 Long-nose pliers Generic product -
8 Tweezers Generic product -
9 Hex wrench
(1.5 to 6 mm)
Generic product -
10 Hex wrench
（2.5mm）
Generic product For screws retaining Head base.
More than 150mm shaft length and not L-
tyoe are recommended.
11 E ring holder (E-
2.5)
Generic product Name: JIS E-2.5
Manufacturer: Iwata Denko Co., Ltd
12 E ring holder (E-6) Generic product Name: JIS E-6
Manufacturer: Iwata Denko Co., Ltd
13 Penlight Generic product -
14 Tube cutter Generic product For replacing solenoid heads and ink tubes
15 Scale Generic product For replacing Steel belt. Longer than 3 meters
is recommended.
No. Name
Part
number
Remarks
1 Personal computer Generic
product
Network interface connector (RJ-45) should
be equipped.
(10M/100M Ethernet I/F)
2 Network interface
cable
Generic
product
Cross-type cable
* Use stratight-type cable to connect HUB.
3 Dedicated network
software
- MUTOH Service Assistance
4 Tension gauge Generic
product
Max. 40 N (4,080gf) for measurement
Manufacturer: Ohba Keiki Seisakusho Co.,
Ltd.
5 Tension gauge Generic
product
Max. 2N (204gf) for measurement
Manufacturer: Ohba Keiki Seisakusho Co.,
Ltd.
6 MF-3G Exclusive
use media
For Paper edge sensor, for print accuracy
adjustment
7 PG height adjustment
jig(1.1/1.3)
DG-43193
For adjusting Head height （1.1mm/1.3mm)
8 level Generic
product
For confirming Installation Environment
9 Cutter Holder
adjustment jig
DG-43191 For assembling Photometer JUNCTION
Board Assy and Cutter Holder
10 Solenoid Head
Washing Kit
DG-41787 For replacing Solenoid Head Assy
11 Solenoid Head
Washing Kit(VJ Ink)
DG-41787 For replacing Solenoid Head.
To Next Page
