2.3 Troubleshooting Without Error Messages VJ1324E-M-02
2.3.1 Initial Operation Problems P.2-36
3
Initial ink charge does not
start
1. Is “Maintenance cover open” displayed on LCD monitor while
Maintenance cover is closed?
• Check the connection of cover sensor Assy
connector.
• Replace cover sensor Assy .
"3.3.3 Replacing Cover Switch
Assy、 Sensor Cover L Assy, Sensor
Cover R Assy" p.3-25
2. Check panel FFC for proper connection at operation panel unit
Assy side and MAIN board Assy side.
• Is the panel FFC inserted obliquely?
• Is the connector securely locked?
Reconnect following connectors.
• MAIN board Assy
• Operation panel unit Assy
"3.4.4 Replacing MAIN Board
Assy" p.3-42
3. Is "Sen: Lever up" displayed on LCD with media set lever
lowered?
Adjust lever sensor.
"3.6.7 Replacing T Fence, T Fence
Spring Assy" p.3-93
4. Check MAIN board Assy connectors for proper connection. • Reconnect the connector.
• Replace lever sensor Assy .
"3.4.4 Replacing MAIN Board
Assy" p.3-42
5. Are the following self-diagnosis functions judged as normal
when checked with specified cartridge securely inserted?
• Presense detection of ink from "Sen: Ink END"
• Presense detection of cartridge from "Ink NOT"
• Follow the steps for the message "[KCMY] No
Cartridge".
• After adjustment/replacement, execute initial ink
charge from "Adj: Input Rank" of self-diagnosis
function.
"3.4.4 Replacing MAIN Board
Assy" p.3-42
"5.10 Parameter Menu" p.5-59
6. Is specified cartridge status judged as normal when checked
through "Sen. : Ink ID" of self-diagnosis function with specified
cartridge securely inserted?
• After adjustment/replacement, execute
initial ink charge from "Adj: Input Rank"
of self-diagnosis function.
7. MAIN board Assy may be damaged. • Replace MAIN board Assy .
• After replacement, execute initial ink charge
from "Adj: Input Rank" of self-diagnosis
function.
"3.4.4 Replacing MAIN Board
Assy" p.3-42
4
Though initial charge has
started, ink does not reach
head.
Is spring of maintenance Assy detached or damaged?
• If the part is detached, remount it.
• If the part is damaged, replace maintenance Assy
.
"3.8.1 Replacing Maintenance
Assy" p.3-138
5
Though ink reaches head,
ink is not discharged from
head.
Is capping position appropriate?
• If ink inflow is confirmed, execute initial ink
charge.
Operation Manual
Table 2-6
Symptoms, Check Items and Actions for Initial Operation Problems (Continued)
No. Symptoms Check Item Action Reference
