P.3-5
3.1 Introduction VJ1324E-M-02
3.1 Introduction
This chapter provides information on removal and replacement of service parts.
WARNING
• Before starting part replacement, always perform the following operations.
• Turn OFF machine power.
• Remove Power plug from outlet.
Otherwise, you may suffer electric shock or system circuit may be damaged.
• Remove any Cables connected to the printer.
Otherwise, the printer may be damaged.
CAUTION
Components in the printer can be disassembled only if so instructed in this manual.
Do not disassemble frame components and other components that are not
instructed to disassemble in the manual.
The printer has been assembled in MUTOH factory with extremely high precision up
to 1/100mm. If disassembled inappropriately, it may not restore its normal
functionality.
NOTE
• After replacing any service parts, perform necessary lubrication and bonding the following
instructions in section "7.5 Lubrication/Bonding" p.7-7.
• The pictures and illustrations of the dis Assy procedure are still under development
The specification of the parts that are not directly related to the procedure may not be up-to-
date.
To Next Page
