2.2 Troubleshooting with Error Messages VJ1324E-M-02
2.2.3 Errors Requiring Reboot P.2-20
(2) Mechanical Serious Errors
No. Message Symptoms Check Item Action Reference
1 E 065Err
PF motor
Abnormal
condition in PF
motor (X-axis)
during printer
operation.
Displayed if
the difference
between motor
command
value and
feedback from
encoder is
large.
1. Check error history from "Test: Record" of self-
diagnosis function.
-
"5.5.9 Record Menu" p.5-18
2. Set the number of endurance running cycles to 50 or
more from "Life: PF motor" of self-diagnosis
function, and check if "PF motor error" occurs.
Check the connection of the following MAIN
board Assy connectors:
• PF motor cable Assy connector
• PF encoder Assy connector
"5.12 Endurance Running
Menu" p.5-71
"3.4.4 Replacing MAIN Board
Assy" p.3-42
3. Check "Encoder: PF" from "Test: Encoder" of self-
diagnosis function.
If NG, check the connection of MAIN board
Assy connector.
"3.4.4 Replacing MAIN Board
Assy" p.3-42
4. Is the area around PF encoder contaminated? Clean around PF encoder.
Replace PF encoder if it is damaged.
"3.5.3 Replacing PF Encoder
Assy" p.3-65
5. Check if MAIN Power Board normally supplies
DC24V.
Replace the power board Assy if it is
damaged.
"3.4.10 Replacing Power Board
Assy" p.3-50
6. PF motor Assy may be damaged. Replace PF motor Assy .
"3.5.1 Replace PF Motor Assy"
p.3-61
7. MAIN board Assy may be defective. Replace MAIN board Assy .
"3.4.4 Replacing MAIN Board
Assy" p.3-42
To Next Page
