2.3 Troubleshooting Without Error Messages VJ1324E-M-02
2.3.2 Media Feed Problems P.2-42
3
4
5
Media wrinkles during media
initialization or printing.
Media tears during media
initialization or printing.
Media size is not correctly
detected after media
initialization.
1. Is suction fan operate normally through "Test6: Fan" of self-
diagnosis function?
• Check the connection of following MAIN
board Assy connectors.
• Suction fan relay Assy : J27
• Replace suction fan Assy .
• Replace cable of suction fan that does not
operate normally.
"3.10.1 Replacing Adsorption FAN"
p.3-149
2. Is shielding material secured at specified position?
Remount it at the specified position.
-
3. When pressure lever is moved backward and forward, does
pressure Assy move smoothly in synchronization with it?
Lubricate pressure cam.
"7.5 Lubrication/Bonding" p.7-7
4. Does pressure roller drag when pressure lever is raised?
If pressure roller collects media dust on itself,
wipe dust away using a wet soft cloth.
Operation Manual
5. Does media guide have large distortion or foreign objects?
• If media guide collects media dust or other
foreign objects on it, remove them.
• Replace media guide.
"3.2.7 Removing Paper Guide R2"
p.3-17
6. When using roll media, are flanges attached correctly?
Insert flanges correctly into core pipe of media
roll.
Operation Manual
Table 2-7 Symptoms, Check Items and Actions for Media Feed Problems (Continued)
No. Symptoms Check Item Action Reference
To Next Page
