About this Manual VJ1324E-M-02
About this Manual
1. Purpose and Target Readers
This manual explains preparations needed before maintaining and checking operations for
MUTOH Full Color Ink Jet Printer (VJ-1324).
This manual is prepared for the maintenance personnel of this printer.
Before using this printer, fully understand the contents and directions in this manual.
2. Manual Configuration
3. Manual Notation
The following symbols are used in this manual for easier understanding of the information.
4. Establishment Date of This Document
This document was established on Mar. 31, 2011.
5. Firmware version covered by this document
Firmware version: V.1.00
Section Contents
1 Safety Instructions Explains types of warnings, cautions and warnings labeled on the printer
for the both operators of the printer and maintenance personnel.
2 Troubleshooting Explains troubles that may occur when using the printer and how to solve
them.
3 Parts Replacement Explains the procedures of replacement and removal of the service parts
of the printer.
4 Adjustment Explains the adjusting procedures of the printer parts.
5 Self-Diagnostic Mode Explains the self-diagnostic functions of the printer.
6 Maintenance Mode 2 Explains the maintenance mode2 of the printer.
7 Maintenance Explains daily maintenance of the printer.
8 Product Overview Explains the features, part names, and functions of the printer.
9 Specifications Explains the specifications of the printer.
10 Appendix Explains the maintenance information and the exploded views for this
printer.
Use the built-in self-diagnostic program to locate a defective part and adjust/check during
maintenance.
Symbol Meaning
Must be followed carefully to avoid death or serious bodily injury
Must be observed to avoid slight or moderate bodily injury or damage
to your equipment
Contains important information and useful tips on the operation of the
product
Indicates useful tips for operating or understanding the equipment
Indicates reference pages in this manual
WARNING
CAUTION
NOTE
TIP
