2.3 Troubleshooting Without Error Messages VJ1324E-M-02
2.3.7 Other Problems P.2-66
6 Ink spills around X rail. 1. The tubes of flushing box or maintenance Assy may be
disconnected.
• Check if the tubes of flushing box or maintenance
Assy are disconnected.
• Replace maintenance Assy .
"3.8 Replacing Maintenance
Section" p.3-138
2. Ink tube may be cut.
3. Print head, MAIN board Assy and CR board Assy may be
defective.
Replace ink tube.
Replace MAIN Board Assy,CR board Assy.
After removing ink cartridge, check if each board
operates properly.
"3.4.4 Replacing MAIN Board
Assy" p.3-42
"3.7.6 Replacing Print Head" p.3-
106
"3.7.4 Replacing CR Board Assy"
p.3-101
Table 2-12 Symptoms, Check Items, and Actions (Continued)
No. Symptoms Check Item Action Reference
