Before using VJ-1324 OPERATION MANUAL
104 3.6 Adjust Print
4. Confirm that the confirmation pattern printing result is as follows.
• Check each of the confirmation patterns A to F.
a. When the printing result is OK;
You do not need perform Adjust Print.
The procedure for Adjustment is complete.
b. When the printing result is ×:
you need to perform Alignment.
• Perform rough adjustment when the misalignment is big.
3.6.2.2 Custom Rough Adjustment Pattern
• Perform micro adjustment when the misalignment is small.
• When all patterns A to F require adjustment:
3.6.2.3.1 Adj. PatternALL
• When any pattern of A to F requires adjustment: 3.6.2.3.2 Each Adjust Patterns
To Next Page
