VJ-1324 OPERATION MANUAL Before using
3.5 Test print 85
• The printing of following items starts.
•Date
• Serial Number
• Color Difference (dE)
26. Check the color difference (dE).
Followings are the commonly recognized indications of color difference (dE).
• dE < 1.0: No discernable difference in color.
• dE < 3.2: Minimally discernable color difference for colors viewed side-by-side.
• dE < 6.5: Minimally discernable color difference for colors in close proximity, not side-by-side.
NOTE
• In order to perform the Color Verify correctly, make sure to specify the following settings same as
the setting when the baseline was saved. If these settings are different, the color difference may
become large.
• Each Heater Temperature Setting, Effect Setting, CR Print Width Setting, Overwrite Setting
• Since the room environment (temperature, humidity) may affect the print color, create the
environment in accordance with the environment condition described in this manual "
8.1.1 Printer
specifications
" "Environment Condition". In addition, make sure to place the media and ink in the
printing environment for 2 hours before use.
• "Color Verify" is a function to check the color variation in print color caused by various causes.
This function is not to guarantee the color reproducibility of the printer.
• Since the judgment of color acceptance is largely dependent on the human eye, we recommend to
perform the print to check the color.
• The message "Update Result?" is displayed on the operation panel.
No. Name
1Date
2 Serial Number
3 Color Difference (dE)
1
2
3
Color Verification
2011/11/01 15:25
Serial No. = XXXXXXXXXX
User Type = Type 3 Head Temp. =25˚CPre Heater = 42˚C
Praten Heater = 42˚C
Dryer = 42˚C
0.30.30.40.10.21.21.10.60.60.50.10.60.6 0.2
dE < 1.0: No discernable difference in color.
dE < 3.2: Minimally discernable color difference for colors viewed side-by-side.
dE < 3.2: Minimally discernable color difference for colors in close proximity, not side-by-side.
