Before using VJ-1324 OPERATION MANUAL
108 3.6 Adjust Print
3.6.2.3 Custom Micro Adjustment Pattern
Check the confirmation pattern, and when the misalignment is small, perform micro adjustment.
This menu is made up with the following menus.
3.6.2.3.1 Adj. PatternALL
Print a Micro Adjustment Pattern ALL and register the setting value.
1. Display the Custom Adjust Print menu on the operation panel in the same way as in step 2 of
"
3.6.2.1 Custom Confirmation Pattern"
2. Press the [+] key or [-] key to select "Adj.3: Fine Ptn. ALL".
3. Press the [Enter] key on the operation panel.
• "Warming Up", and then "Warming Up Skip -> E" are displayed.
Menu Name Description Reference
Custom Micro
Adjustment
Pattern
Adj. PatternALL Adjust all confirmation patterns A to F.
3.6.2.3.1 Adj. PatternALL
Each Adjust
Patterns
Adjust all confirmation patterns A to F.
3.6.2.3.2 Each Adjust Patterns
To Next Page
