VJ-1324 OPERATION MANUAL Handling the printer
4.4 Operating from the operation panel 135
4.4 Operating from the operation panel
This section explains various functions that can be operated from the operation panel.
TIP
•For names and functions of each key, refer to "2.2.3 Operation panel".
4.4.1 Feeding media
You can feed the roll media at a position that you want.
Follow the procedure below to feed media.
1. Confirm that the operation panel is Normal.
2. Make sure that the media loading lever is lowered.
3. Press the [Forward↓] key or the [Backward↑] key on the operation panel.
• Media is fed forward or backward.
4. Release the [Backward↑] key or [Forward↓] key on the operation panel after feeding media to the
desired position.
To Next Page
