VJ-1324 OPERATION MANUAL Handling the printer
4.5 Using spectrophotometer (SPECTROVUE VM-10) 155
23. Remove the white reference plate from the plate installation place, turn it over so that the black side
faces up, and install it back to the original place.
NOTE
• When the white reference plate is not in use, make sure that it is turned over facing down to avoid
any contamination.
24. Close the maintenance cover.
• "Ready to Print" is displayed on the operation panel.
• For the subsequent operations, follow the instructions of the RIP software.
No. Name
1 White reference plate
2 Plate installation place
No. Name
1 Maintenance cover
1
1
2
2
3
1
To Next Page
