Panel setup menu VJ-1324 OPERATION MANUAL
168 5.1 Setup menu
(2) Init.Adj.Change menu
Sets up Initial Adjust Change.
(3) Confirm Print menu
Performs Confirm Print.
(4) Micro Print menu
Performs Micro Adjustment Print.
Setup item Setting Description
Init. The set value ±50.0mm in
"Feed length" of Initial adjust
print
Sets up Initial Adjust Change.
e.g) When the set value in "Feed length*" of Initial adjust print
is set to 250mm, the adjustment range in this menu is 200mm
to 300mm.
— • [Enter] key: saves the setting and shifts to the previous
menu.
• [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.4 Dist.Adj menu
Setup item Setting Description
FeedLength 100mm to <250mm> to
500mm
Changes the length (feed length) of the media feed direction
for Confirm Print.
• [Enter] key:
Determines the setting.
"Printing" is displayed on the operation panel and Initial
Print starts.
After printing, the printer enters Normal.
— • [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.4 Dist.Adj menu
Setup item Setting Description
Micro Print Printing Prints the following PF pattern (micro adjustment) with a
focus on the micro adjustment value.
•0%, ±0.05%, ±0.1%, ±0.2%
— • [Cancel] key: shifts to the previous menu.
Stops printing and returns to the previous menu if printing
is in progress.
5.1 Setup menu
