Maintenance
VJ-1324 OPERA
TION MANU
AL
238
6.2 Cleaning the printer
9.
Press the
[Enter] key on the operation panel.
•
The print head returns to its original position.
•
"CR Maine.: S
tart" is displayed on the operation panel.
10.
P
ress the [Menu] key on the operation p
anel.
•
The printer enters Normal.
•
Cleaning around the pr
int head is complete.
237
239
