VJ-1324 OPERA
TION MANUAL
Appendix
8.1 Product specifications
265
Power
Power voltage
AC 90 V to AC 132
V / AC 198 V to AC 264 V
Frequency
50 Hz/60 Hz ± 1 Hz
Power consumption
Printing
1550W or less
Standby
44W
Outer diameter
He
ight
1218mm (including the stands)
W
idth
1916mm
Depth
685mm
W
eight
Printer
61kg
Stands
21.3kg
Items
Specification
264
266
Table of Contents
Default Chapter
3
Important Notice
3
Warranty Limitations
5
About this Manual
6
Contents of the Manual
6
Installation Manual
6
Manual Configuration
6
Table of Contents
9
1 Safety Instructions
15
Types and Meanings of Warnings
16
Important Safety Instructions
17
Warning Labels
21
Handling the Warning Labels
21
Location and Type of Warning Labels
22
Operating Instruction Labels
23
Cautions on Handling the Operating Instruction Labels
23
Locations and Types of Operating Instruction Labels
23
2 Product Overview
25
Features
26
Names of Parts and Functions
27
Front Section
27
Rear Section
28
Operation Panel
29
Ink Level Indicator
33
Estimated Ink Level Graphic
34
Printer Status
35
Normal
35
Setup Menu Display
35
Changing Printer Status
35
3 Before Using
37
Power Cable Connection
38
Turning the Power ON/OFF
42
Turning the Power on
42
Turning the Power off
43
Installing Ink Cartridges
45
Installing 220Ml Ink Cartridges
47
Installing High Capacity Pack Adapters (Option)
51
The First Time
55
Loading Media
56
Loading Roll Media
56
Setting Roll Media
59
Setting the User Type Setting
63
Test Print
65
Nozzle Check
68
Mode Print
69
Setup Print
70
Palette Print
71
Color Verify
72
Specifications
85
Adjust Print
87
Standard Adjust Print
88
Standard Confirmation Pattern
93
Standard Rough Adjustment Pattern
93
Standard Micro Adjustment Pattern
96
Custom Adjustment Pattern
99
Custom Confirmation Pattern
105
Custom Rough Adjustment Pattern
105
Adj. Patternall
108
Custom Micro Adjustment Pattern
108
Each Adjust Patterns
111
Connecting the Printer to PC
114
System Requirements
114
Preparing Cables
114
Connecting a Network Interface Cable
115
4 Handling the Printer
117
Print Flow Chart
118
Media
119
Media Type
119
Cautions on Handling Media
120
Precaution on Storing Media
120
Printing Area
121
Head Height Adjustment
121
When Raising the Print Head
122
When Returning the Print Head to the Original Position
124
Media Feed Compensation
126
Menu Setups on the Operation Panel
132
Menu Setup Procedure
132
Panel Setup Menu Overview
134
Operating from the Operation Panel
135
Feeding Media
135
Stopping Printing Operation
136
Cutting Media
137
Cutting Media Manually
138
Changing and Confirming Settings While Printing
139
Procedure for Changing and Confirming Settings While Printing
139
Settings that Can be Changed or Confirmed While Printing
140
Pausing Printing
141
Start Printing During Warm up
142
Normal Display While Printing
143
Using Spectrophotometer (SPECTROVUE VM-10)
145
5 Panel Setup Menu
157
Setup Menu
158
User Type Menu
160
Print Mode Menu
162
Effect Menu
163
Adjust Print Menu
165
Dist.adj Menu
167
Pre-Heater Menu
169
Platen Heater Menu
170
Dryer Menu
171
Vacuum Fan Menu
171
Spitting Menu
172
Spitting Pass Count Menu
173
Side Margin Menu
175
Media Initial Menu
176
Media Width Menu
177
Output Mode Menu
178
Ink Drying Time Menu
178
Method of Cut Menu
179
Cut Pressure Menu
179
Origin Menu
180
Prev. Stick Menu
182
Standbyheating Menu
182
Head Travel Menu
183
Multi Strike Menu
183
Strike Wait Menu
184
Slant Check Menu
184
Auto Cleaning Menu
185
Idle Auto Cleaning
185
Pre-Printing Mode Auto Cleaning
186
Printing Mode Auto Cleaning
186
Ink Status Menu
187
Smartchip Menu
187
Roll Length Menu
187
Longstore Menu
188
CR Maintenance Menu
189
Initialization Menu
189
Life Times Menu
190
IP Address Menu
190
Subnet Mask Menu
191
Gateway Menu
191
Header Dump Menu
192
Test Print Menu
193
Cleaning Menu
194
Menu Option Menu
195
Version Menu
198
Sleep Mode Menu
199
Timer Setting Menu
200
Sleep Mode Start Menu
201
Display Menu
202
Language Menu
202
Temperature Menu
202
Length Menu
203
Remain Ink Menu
203
Job Status Menu
204
6 Maintenance
205
Replacing Consumable Components
206
Replacing Ink Cartridges
206
Replacing Roll Media
211
Replacing Cutter
214
Cleaning the Printer
222
Cleaning the Outer Case
223
Cleaning the Inside of the Printer
224
Head Cleaning
226
Cleaning the Cleaning Wiper
227
Cleaning Around the Print Head
232
Disposal of Waste Fluids
239
Moving or Transporting the Printer
241
Moving the Printer
241
Transporting the Printer
243
7 Troubleshooting
245
Malfunctions and Failures
246
Problems in Installation and Introduction
246
Cannot Print at All
246
Nothing Is Printed
247
Media-Related Troubleshooting
248
Printing-Related Troubleshooting
250
Error Messages
253
Status Messages
253
Message Type Error Display and Remedies
254
Error Requiring Restart
258
The Media Is Jammed
259
8 Appendix
263
Product Specifications
264
Printer Specifications
264
Interface Specification
266
Network Interface Specification
266
Options/Supply List
267
9 Setup Menu Diagram
269
Revision History
275
