Before using VJ-1324 OPERATION MANUAL
92 3.6 Adjust Print
NOTE
• To start printing during warming up, press the [Enter] key while "Warming Up Skip -> E" is
displayed.
4.4.7 Start Printing during Warm up
• A confirmation pattern for print quality adjustment is printed after warming up.
• A confirmation pattern is printed.
• After the confirmation pattern is printed, "Adj.1: Confirm Ptn." is displayed on the operation
panel.
4. Confirm that the confirmation pattern printing result is as follows.
a. When the printing result is OK;
You do not need perform Adjust Print.
The procedure for Adjustment is complete.
b. When the printing result is ×:
you need to perform Alignment.
• Perform rough adjustment when the misalignment is big.
3.6.1.2 Standard Rough Adjustment Pattern
• Perform micro adjustment when the misalignment is small.
3.6.1.3 Standard Micro Adjustment Pattern
To Next Page
