Before using VJ-1324 OPERATION MANUAL
94 3.6 Adjust Print
4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the
number from 1 to 11 that is not out of alignment.
• "4" is selected in the next printing sample.
NOTE
• "6" is the current setting value.
5. "Pattern *: 6" (* indicates a pattern name as shown below) is displayed on the operation panel.
• The pattern name (*) differs depending on the set print mode.
The print modes and their pattern names are as follows.
6. Press the [+] key or [–] key to enter the number that you selected in Step 4.
NOTE
• When you press the [Cancel] key, the input operation is not executed and "Adj.2: Rough Pattern"
is displayed on the operation panel.
PrintMode PatternName
Quality 1, 2 C
Quality 3, 4 B
Graphics 1, 2 E
Graphics 3, 4 D
Banner 1, 2 A
Banner 3, 4 A
To Next Page
