8 - 12

Cylinder heads

9.612.0.006.7160 - 05/04

Measure the outer diameter of the valve stem in 3

different points:

• Upper part

• Central part

• Lower part

Measure the outer diameter of the valve guide.

Attention

• Do not measure the diameter on the lowered part of the guide.
