4 - 4
Engine Block
9.612.0.006.7160 - 05/04
Pre-Assembly Inspections and Measurements
Liners Specification
Liners
Measure mm
Maximum waste 0.06
Out-of-roundness 0.02
Ø Inner 105.000 - 105.022
