13 - 6
Cooling System
9.612.0.006.7160 - 05/04
Assembly the water pipe and by-pass pipe with new
sealing rings. Tighten all bolts with the specified
torque.
Assembly
Assembly the thermostat in the carcass with a new
sealing ring.
Cautions
• Never operate the engine without the thermostat, because the engine will not reach the
correct operation temperature.
• The sealing rings of the component disassembled must be always changed.
