MWM Acteon - Bolts Tightening Torques Specification

10 - 4
Flywheel and Flywheel Housing
9.612.0.006.7160 - 05/04
Bolts Tightening Torques Specification
Pre-torque 100 ± 10 Nm Lmax= 36,00 mm
Final 275 ± 15 Nm
100 ± 15 Nm
100 ± 15 Nm
100 ± 15 Nm
Tighten sequence
100 ± 15 Nm
8 ± 2 Nm
250 + 20 Nm *
* For the application 17.260E OT, apply chemical lock.
