MWM Acteon - Camshaft Specifications

Camshaft
6 - 3
9.612.0.006.7160 - 05/04
Camshaft Specifications
Gear seat
Diameter (A) mm
Nominal 51.971 - 51.990
Axial Clearance Limitation Groove
Width (B) mm
Nominal 7.100 - 7.190
Maximum 7.275
Main journals
Diameter (C) mm
Standard 49.920 - 49.940
Bearing Clearance mm
Axial 0.05 - 0.19
Radial 0.05 - 0.13
