11 - 2
Balancer Unit
9.612.0.006.7160 - 05/04
Disassembly Notes
After removing the carter, carefully remove the oil
suction pipe in order to do not let the sealing ring to
fall inside the suction gallery.
Remove the deflector of the balancer unit. Loosen the
balancer bolts and carefully remove it to do not loosen
the bearing. Keep the guide-pins on their positions.
Remark
The balancer unit is an exclusive item of the 4 cylinders engines, especially in vehicular applications.
It is not recommended its removal because that, despite does not affect the useful life of the engine, can cause
excessive vibration on the systems connected to the engine (vehicle cabin, connections, etc).
