Flywheel and Flywheel Housing
10 - 5
9.612.0.006.7160 - 05/04
Assembly
To install the gear ring on the flywheel, first heat it up
to a temperature of about 250°C and assembly paying
attention to the assembly position of the chamfer
indicated by an arrow.
Well clean the carcass and the engine block. Apply a
layer of Loctite 515 on the contact surface between
the engine block and the carcass, surrounding the
holes of the bolts.
Assembly the carcass on the engine block and tighten
the bolts according to the specification and crosswise.
