Pistons and Connecting Rods
7 - 9
9.612.0.006.7160 - 05/04
Radial Clearance (mm)
Nominal 0.022 - 0.087
Maximum 0.178
Connecting Rods Specifications
Side Clearance (mm)
Nominal 0.30 - 0.50
Maximum 0.90
