MWM Acteon - Liners and Pistons Assembly Specifications

Engine Block
4 - 5
9.612.0.006.7160 - 05/04
Liners and Pistons Assembly Specifications
1
Piston
2
Liner
3
Engine Block
4
Gasket
Liners Assembly
W X Y Z Gasket nr. / Application
0.23 to 0.59
8.04 to 8.06 0.95 to 1.10 1.35 to 1.69 9.612.0.854.003.4 / Spare part
5
Cylinder head
