6 - 4
Camshaft
9.612.0.006.7160 - 05/04
Tappets and Lock Plate Specification
Ø
Lock Plate
Thickness
Nominal
Tappets
Diameter mm
Standard
Nominal 17.983 - 17.994
Minimum 17.975
1st repair
Nominal
18.483 - 18.494
mm
7.00 - 7.05
