Cylinder heads
8 - 17
9.612.0.006.7160 - 05/04
Bolts Tighten Torques Specifications
56 ± 8 Nm
20 + 6 Nm
15 + 5 Nm
15 + 5 Nm
110 ± 15 Nm
Torque - Angle
Step
1st...................... 60 + 10 Nm
2nd ..................... 60° ± 3°
3rd ...................... 60° ± 3°
Lmax = 148.50 mm
