Gearing Carcass
9 - 7
9.612.0.006.7160 - 05/04
Bolts Tightening Torques Specification
5 + 5 Nm
20 ± 3 Nm
60 ± 5 Nm
5 + 5 Nm
20 ± 3 Nm
20 ± 3 Nm
Tightening sequence
8.5 ± 1 Nm
