Flywheel and Flywheel Housing
10 - 7
9.612.0.006.7160 - 05/04
Check the side oscillation of the flywheel.
Maximum side
oscillation = 0.30 mm
Check the parallelism of the flywheel in relation to the
housing.
Maximum parallelism = 0.20 mm
Dynamic
Balancing = Holes ø10 x 12 mm
maximum, in a ray of
197 mm.
Acceptable
unbalancing = 425 g.mm.
Assembly the speed sensor and apply the specified
torque.
