12 - 4

Lubrication System

9.612.0.006.7160 - 05/04

Visually check the drive gear of the oil pump, the inner

part of the carcass and the rotor, for damages or

excessive waste.

Check the clearance between oil pump rotors.

Clearance between rotors: 0.05 - 0.10 mm

Check the radial clearance between the outer rotor

and the pump carcass.

Radial clearance: 0.06 - 0.10 mm

Check rotors axial clearance.

Axial clearance: 0.025 - 0.075 mm
