Engine Block
4 - 7
9.612.0.006.7160 - 05/04
Camshaft Bearing (C) and (E)
Ø inner mm
without bushing
standard nominal 50.000 - 50.025
maximum 50.045
1st repair
without bushing 54.000 - 54.030
with bushing 49.990 - 50.050
Camshaft Bearing (D)
Ø inner mm
without bushing 54.000 - 54.030
with bushing 49.990 - 50.050
*Remark.: Camshaft bearing (D) has originally bushing and the others do not.
When it is necessary the other bearings can receive bushing as repair.
