MWM Acteon User Manual

Engine Block
4 - 9
9.612.0.006.7160 - 05/04
Temporarily install the liner in the engine block, with
the Tombak ring but without the rubber sealing rings.
Lubricate with engine oil the contact area of the liner
with the sealing rings, if they are assembled in the
engine block.
To measure liner protrusion with the sealing rings
installed, compress the liners using the special tool
MWM nr. 9.610.0.690.025.4.
Torque at 40 Nm.
