5 - 14
Crankshaft
9.612.0.006.7160 - 05/04
Remove one of the bolts of the bearing and measure
bearing pre-tension.
Pre-tension: 0.025 - 0.060 mm.
Assembly bearing caps and tighten according
specification. Perform the measurements in the same
way that they were performed for the bearings without
bearing shells to obtain the radial force.
The 1st measurement is made in the centre of the
bearing.
