Pistons and Connecting Rods
7 - 7
9.612.0.006.7160 - 05/04
Ring Ends Gaps Specification
Connecting Rod Bearing, Ø (bore)
Diameter (mm)
standard 62.992 to 63.037
repair 1 62.746 to 62.791
repair 2 62.496 to 62.541
repair 3 62.246 to 62.291
repair 4 61.996 to 62.041
Ends Gap (mm)
1st and 2nd groove
Nominal 0.40 - 0.65
Maximum 2.0
3rd groove
Nominal 0.25 - 0.55
Maximum 2.0
Connecting Rod Bearings Specification
