Pistons and Connecting Rods
7 - 19
9.612.0.006.7160 - 05/04
Carefully push the piston inside the cylinder. Never hit
directly on the top of the piston.
Install the device for piston assembly to close the
rings.
Note: Position the engine flywheel upward. This avoids
the contact of the connecting rod with the oil
injectors.
Lubricate the two inner halves of the bearing shells.
