Resistance and Resistivity
Resistance is the opposition that charges encounter when moving
through a material.
The ohm is the common unit of resistance measurement. It is the
resistance of a conductor when a voltage of one volt produces a
current flow of one ampere along the conductor. Resistance may also
be measured in milliohms (0.001 Ohm) or in megohms (1,000,000
Ohms).
Common symbols for resistance are:
• R, r
• Ω (Greek letter omega)
Resistance is important in such matters as cathodic protection
groundbeds, resistance of a structure to the electrolyte, and the linear
resistance of a long structure such as a pipe or cable.
Resistivity is the resistance of a conductor of unit length and unit
cross-sectional area.
The symbol used for resistivity is ρ (Greek letter rho).
Resistivity is constant for a given material and is computed by the
formula:
L
AR
×
= ρ
where ρ = Resistivity in ohm-cm
R = Resistance in Ohms
A = Cross-sectional area in cm
2
L = Length in cm
If the resistivity of a material is known (see Table 1.1), the resistance
of a conductor such as a cable or pipeline of known length and cross-
sectional area can be calculated from:
A
L
R
×
=
ρ
