Native Instruments MASCHINE MK3 Getting Started

2. In the Control area below, click the SOUND tab to select the Sound level, since you want
to apply the saturation to a Sound.
3. The actual Sound that you assign the effect to is always the one in focus. Hence, at the
left of the Pattern Editor, click the Sound slot’s name (Analovue) to select that Sound
slot.
4. At the far left of the Control area, click the small plug icon to display the Plug-ins.
This displays the Plug-in List on the left of the Control area:
The Plug-in List in this instance contains Massive.
Applying Effects
Loading Effects
MASCHINE - Getting Started - 108

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
