Native Instruments MASCHINE MK3 Getting Started

1. Turn the LINE OUT VOLUME knob on the rear panel of the MASCHINE controller to the
left-end stop to set the output volume to minimum.
2. Connect the LINE OUT L/R sockets on the rear panel of the MASCHINE controller to your
active speakers using balanced cables with 1/4" TRS jack plugs. First, connect the L out-
put channel with the left speaker, then the R output channel with the right speaker.
3. Once you have connected the speakers to the device, set the volume knob on your active
speakers to 0 dB and turn them on.
4. Start the playback of a Project in MASCHINE or an audio file on your computer.
5. Gradually turn the LINE OUT VOLUME knob on the rear panel of the MASCHINE control-
ler until you reach an appropriate listening level.
If you have a main mixer connected to your monitors, and various devices plugged into
your main mixer, you can simply add the MASCHINE controller to your setup by con-
necting its audio outputs to any stereo line input on your main mixer. Just follow the in-
structions above and replace the monitors’ volume knob with the volume fader of the in-
put channel on your mixer to which you want to connect the MASCHINE controller.
Setting Up MASCHINE
Setup Examples
MASCHINE - Getting Started - 24

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
