V10/V7.5/V5/V3.5 Installation and Operation Manual Page 1-3
Section 1 General Information Issue 3.5
Table 1-2: Recommended Site Test Equipment
NOMENCLATURE
PART/MODEL NUMBER OR TYPE
(EQUIVALENTS MAY BE USED)
APPLICATION
Dummy Load
50 Ω
Minimum power rating of 15,000 W (V10),
10,000 W (V7.5), 7,500 W (V5) or 5,000
W (V3.5)
VSWR 1.1 (87.5 – 108 MHz)
'Off-air' testing
Digital Multimeter
3 1/2 digit, ac and dc volts (10 MΩ input),
ohms and amps, ±0.5% accuracy, Fluke
179 or equivalent
Testing and
maintenance
Oscilloscope Tektronix Model TDS2022 Testing and
maintenance
Modulation Monitor Belar Model FMM-2 or equivalent
Modulation level setup
and performance
monitoring
Spectrum Analyzer HP4396B or equivalent Hybrid/All-Digital mode
output spectrum testing
Audio Signal
Generator
10 Hz to 20 kHz, 600 Ω,
0 to +15 dBm
Audio Precision SYS-2 or equivalent
Simulates modulating
audio during testing
and maintenance
Distortion Analyzer 20 Hz to 20 kHz
Audio Precision SYS-2 or equivalent
Measures audio
distortion during testing
and maintenance
Dc Power Supply
(Variable)
0 – 30 V, 1 A Testing and
maintenance
Torque Screw Driver
(Phillips head)
Capable of torquing to six inch-pounds
(0.672 Newton-Meters)
Installing power
amplifier pallets or
reject load resistors
Hex Wrench
(Allen Key)
3/16 inch
Capable of torquing to 120 in-lbs
(Nautel Part # HY80 in ancillary kit)
Terminating wires on
ac terminal block
