Nautel V10 - System Configuration

Page 3-30 V10/V7.5/V5/V3.5 Installation and Operation Manual
Issue 3.5 Section 3 Operating Instructions
(c) Press Save to store the setting.
(d) Press Back to return to previous
menu.
3.6.12.7 System Configuration
The system configuration is factory set to
the customer’s requirements. No user
adjustment should be required.
(a) Use f or g to highlight System
Config, RF Modules, FM+HD Bias or
ALC Limit. Press Edit on the desired
field and use f or g to select
between the available options:
• System Config: Stand Alone, Exctr.
Ctrl: Master, Exctr,Ctrl: Slave or SC1
• RF Modules: Analog or Digital
• FM+HD Bias: FM+HD or HD (allows
the use of HD bias levels in FM+HD
mode)
• ALC Limit: adjust between 65% and
135% (typical range is 95 -105 %)
• Exc Chgovr Dly (FM): adjust the time
delay for an exciter changeover (in FM
mode only) between 1 and 60 s
• Preset Synch: Enable (default setting;
forces the M50 to select the same
active preset as the transmitter) or
Disable
NOTE
The preset synchronization feature only
selects the M50’s preset. The associated
preset parameters (mode, frequency, etc.)
on the M50 must still be manually
matched to the transmitter.
The M50’s firmware must support the
preset synchronization feature. If you are
unsure of the M50’s firmware
compatibility, set the Preset Synch to
Disable.
Top of Screen
System Configuration
System Config: Stand Alone
RF Modules: Analog
FM+HD Bias: FM+HD
ALC Limit: 100%
Exc Chgovr Dly(FM):1 s
Edit Back
11:26 98.10MHz 0.00kW 1 ExA IPAA/A FanA
System Configuration
System Config: Stand Alone
RF Modules: Analog
FM+HD Bias: FM+HD
ALC Limit: 100%
Exc Chgovr Dly(FM):1 s
Edit Back
11:26 98.10MHz 0.00kW 1 ExA IPAA/A FanA
Bottom of Screen
System Configuration
RF Modules: Analog
FM+HD Bias: FM+HD
ALC Limit: 100%
Exc Chgovr Dly(FM):1 s
Preset Synch: Enable
Edit Back
11:26 98.10MHz 0.00kW 1 ExA IPAA/A FanA
System Configuration
RF Modules: Analog
FM+HD Bias: FM+HD
ALC Limit: 100%
Exc Chgovr Dly(FM):1 s
Preset Synch: Enable
Edit Back
11:26 98.10MHz 0.00kW 1 ExA IPAA/A FanA
E-H (or E-G for V7.5) Rej Pwr High and
O/P Rej Pwr High used in V10/V7.5
only. Display reads Unused for V5/V3.5.
4/4
3/4
1/4
2/4
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
SWR Shutback 600 W
IPA Forward High 350 W
IPA Forward Low 50 W
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
SWR Shutback 600 W
IPA Forward High 350 W
IPA Forward Low 50 W
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
IPA Forward vs Volts 0%
IPA Input High 19 W
IPA Input Low 3 W
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
IPA Forward vs Volts 0%
IPA Input High 19 W
IPA Input Low 3 W
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
IPA Reflected High 75 W
A-D Rej Pwr Shutback 600 W
E-H Rej Pwr Shutback 600 W
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
IPA Reflected High 75 W
A-D Rej Pwr Shutback 600 W
E-H Rej Pwr Shutback 600 W
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
O/P Rej Pwr Shutback 600 W
Low Forward Power 50 %
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
Setup Thresholds
Preset 1 98.10 MHz FM 5.50 kW
O/P Rej Pwr Shutback 600 W
Low Forward Power 50 %
Edit Back
11:26 98.10MHz 0.00kW 1 EXA IPAA/A FanA
