Communicating with the receiver.
After connecting to the receiver, serial port setting can be seen in the left part of the main window.
Two graphical indicators show connection activity between PC and the receiver. Transmission
errors field shows a number of errors occurred when receiving data from the receiver. Request
packet checkboxes become enabled as well. If a certain checkbox is checked, a dialog window
corresponding to that packet pops up. The window closes upon unchecking the checkbox.
To break the connection between PC and the receiver click "Stop" button in the main window.
