AVIOR-24S ™ Appendix B

avis Standard Interface Protocol BINR

NAVIOR-24S ™ Revision V1.00 20.05.2008

SW version info

Request Packet 1Bh

Packet 1Bh requests SW version. Packet 70h is the get packet. Packet 1Bh contains no data and has

following structure:
