N
AVIOR-24S ™ CHAPTER IV
Operation and Performance
63
NAVIOR-24S ™ Revision V1.00 20.05.2008
NAVIOR-24S GPS/GLONASS Receiver interference mask
NAVIOR-24S GPS/GLONASS Receiver with antenna M102 provides interference mask immunity,
shown on Figure IV-1.
-160
-140
-120
-100
-80
-60
-40
-20
0
1315 1525 1562 1584 1593 1609 1614 1635 2000 2500
MHz
dB
GLONASS GPS
Figure IV-1. Interference mask immunity
